Area of use

«Ultrasonic-Sektor-24-GSM» suppressor is intended for use in office and meeting rooms and is installed under the negotiation table. With proper installation, you will be able to make recording, while recording by interlocutors will be impossible. The ultrasonic effect on microphones and voice recorders, as well as the operation of the built-in communication suppressor, will protect the room as much as possible from information leakage.

Features Operation invisible to others. The suppressor is installed under the table and operates silently, so your interlocutors will not be aware of its use.   You can record a conversation, but the rest can not! Ultrasonic emitters are arranged in such a way that you are the only one able to record.   Ultrasonic Sound Suppression. The suppressor is equipped with 24 ultrasonic emitters impacting the microphone membranes of any recording devices, thereby making sound recording impossible.   Data transfer block. The built-in communication suppressor blocks communication in the GSM, Wi-Fi, 3G, 4G, LTE, GPS bands, making it impossible to transmit information.   The remote control allows for the remote control of suppressor’s operation, without attracting the unwanted attention.   Ability to operate using battery (optional). Allows you to use the suppressor autonomously for up to 2 hours, which will be useful in the absence of a 220V network in the place of use of the device.   Protection against laser microphones (optional). At your request, this device can be equipped with special vibro-acoustic emitters that interfere with the remote reading of information off the window glass of the meeting room and provide reliable protection from laser microphones.



Additional modules

Splitter and piezo-vibration emitters





Optimal placement scheme for Ultrasonic-Sektor-24-GSM

Technical Specifications

31 Suppression Standard:

Frequency Range: 925-960 MHz

Standards:

• GPRS (downlink): 925-960 MHz
• EDGE (downlink): 925-960 MHz
• UMTS (downlink): 925-960 MHz
• GSM-900 (downlink): 925-960 MHz
• EGSM (downlink): 925-960 MHz

Frequency range: 1805-1880 MHz

Standards:

• EDGE (downlink): 1805-1880 MHz
• GPRS (downlink): 1805-1880 MHz
• HSUPA (downlink ): 1805-1880 MHz
• DCS (downlink): 1805-1880 MHz
• LTE B3 (downlink): 1805-1880 MHz
• GSM-1800 (downlink): 1805-1880 MHz

Frequency range: 790-826 MHz

Standards:

• AMPS / D-AMPS : 790-826 MHz
• LTE B20 (downlink): 791-821 MHz

Frequency range: 850-894 MHz

Standards:

• LTE B5 (downlink): 869-894 MHz
• GSM-850 (downlink): 869-894 MHz
• ZigBee: 868 MHz
• PD868 : 868 MHz
• CDMA: 850-890 MHz

Frequency range: 2110-2170 MHz

Standards:

• IMT-MC (downlink): 2110-2170 MHz
• W-CDMA (downlink): 2110-2170 MHz
• HSDPA (downlink): 2110-2170 MHz
• HSPA + (downlink): 2110-2170 MHz

Frequency range: 2400-2500 MHz

Standards:

• Wi-Fi: 2400-2500 MHz
• Bluetooth: 2450-2485 MHz
• RC 2.4G (video signal): 2400-2500 MHz

Frequency range: 1570-1610 MHz

Standards:

• GLONASS L1 (1st generation): 1602 MHz
• GLONASS L1 (2nd generation): 1600.995 MHz
• GPS L1: 1575.42 MHz
• GLONASS L1 (3rd generation): 1575.42 MHz

Frequency range: 2620-2690 MHz

Standards:

• WiMax: 2620-2690 MHz
• LTE B7 (downlink) : 2620-2690 MHz



• Ultrasonic emitters: 24 pcs.
• Communication suppressor: from 5 to 15 meters
• Angle of attack: 255 degrees
• External power supply: 12V, 3A
• Dimensions: 300x150x40 mm

Package

1. Ultrasonic-Sektor-24-GSM suppressor - 1 pc.
2. 12V network adapter - 1 pc.
3. Remote control - 1 pc.
4. Manual - 1 pc.
5. Battery (optional)
6. Vibration protection kit for laser microphones (optional)
