Area of use

The ultrasonic suppressor of voice recorders, mobile communications and the Internet «Ultrasonic-SpyLine-24-GSM» is specially designed for use in offices and meeting rooms to block unauthorized audio recording and data transfer.

The device is mounted under the leader’s table or negotiation table using special fasteners and does not attract attention when used. Ultrasonic suppression of voice recorders has a directional effect, which must be taken into account when installing the suppressor.

Features Stealth work! The device is installed under the negotiation table using a special mount in such a way that it does not attract the attention of the interlocutors and works silently.   You can record a conversation, but your interlocutors can not! Ultrasound emitters are arranged in such a way that only you can record on the recorder, while the recordings of other negotiators will be corrupted.   Ultrasonic suppression. The presence of 22 built-in ultrasonic emitters ensures suppression of recordings of any type at a distance of 10 meters.   Wireless suppression. The suppressor spreads interference in 8 radio frequency bands and blocks 3G and 4G mobile Internet, GSM 900/1800 cellular communications, GPS navigation, and Wi-Fi networks.   Remote control. The suppressor is controlled using the remote control, which allows using the device without attracting attention.   Battery operation (optional). The suppressor can be equipped with a built-in battery and operate autonomously for up to 2 hours, which will allow using it, for example, in field calls.   Protection against laser microphones (optional). At your request, this device can be equipped with special vibro-acoustic emitters that interfere with the remote reading of information from the window glass of the meeting room and provide reliable protection from laser microphones.



Additional modules

Splitter and piezo-vibration emitters





Optimal placement scheme for Ultrasonic-SpyLine-24-GSM

Technical specifications


31 Suppression Standard: (more information on suppressed communication standards)

Frequency Range: 925-960 MHz

Standards:

• GPRS (downlink): 925-960 MHz
• EDGE (downlink): 925-960 MHz
• UMTS (downlink): 925-960 MHz
• GSM-900 (downlink): 925-960 MHz
• EGSM (downlink): 925-960 MHz

Frequency range: 1805-1880 MHz

Standards:

• EDGE (downlink): 1805-1880 MHz
• GPRS (downlink): 1805-1880 MHz
• HSUPA (downlink ): 1805-1880 MHz
• DCS (downlink): 1805-1880 MHz
• LTE B3 (downlink): 1805-1880 MHz
• GSM-1800 (downlink): 1805-1880 MHz

Frequency range: 790-826 MHz

Standards:

• AMPS / D-AMPS : 790-826 MHz
• LTE B20 (downlink): 791-821 MHz

Frequency range: 850-894 MHz

Standards:

• LTE B5 (downlink): 869-894 MHz
• GSM-850 (downlink): 869-894 MHz
• ZigBee: 868 MHz LPD868 : 868 MHz
• CDMA: 850-890 MHz

Frequency range: 2110-2170 MHz

Standards:

• IMT-MC (downlink): 2110-2170 MHz
• W-CDMA (downlink): 2110-2170 MHz
• HSDPA (downlink): 2110-2170 MHz
• HSPA + (downlink): 2110-2170 MHz

Frequency range: 2400-2500 MHz

Standards: Wi-Fi: 2400-2500 MHz

• Bluetooth: 2450-2485 MHz
• RC 2.4G (video signal): 2400-2500 MHz

Frequency range: 1570-1610 MHz

Standards:

• GLONASS L1 (1st generation): 1602 MHz
• GLONASS L1 (2nd generation): 1600.995 MHz
• GPS L1: 1575.42 MHz
• GLONASS L1 (3rd generation): 1575.42 MHz

Frequency range: 2620-2690 MHz

Standards:

• WiMax: 2620-2690 MHz
• TE B7 (downlink): 2620-2690 MHz



• Ultrasonic emitters: 22 pcs.
• Total output power: 4 W;
• Communication suppressor: from 5 to 15 meters
• Angle of attack: 75 degrees
• External power supply: 12V, 3A
• Dimensions: 400x100x30 mm

Package content

1. The "Ultrasonic-SpyLine-24-GSM" suppressor - 1 pc.
2. 12V network adapter - 1 pc.
3. Remote control - 1 pc.
4. Manual
5. Battery (optional)
6. Vibration protection kit for laser microphones (optional)
